Specifications

• Dimensions

  add remove
  • Length:
    95.1 in
  • Overall width:
    36.6 in
  • Overall height:
    57.8 in
  • Seat height, unladen:
    27.0 in
  • Ground clearance:
    4.6 in
  • Rake (steering head):
    30
  • Trail:
    5.7 in
  • Wheelbase:
    64.2 in
  • Tires, front specifications:
    130/90B16,73H,BW
  • Tires, rear specifications:
    150/80B16,77H,BW
  • Fuel Capacity:
    5.0 gal
  • Oil capacity:
    5 qt.
  • Weight, as shipped:
    710 lbs
  • Weight, in running order:
    742 lb
  • Luggage capacity – volume:
    1.5 cu ft (0.043 m³)
  • Tire, type:
    Dunlop® Harley-Davidson Series, bias blackwall front and rear
  • Fork angle:
    30
  • Reserve fuel capacity, fuel injection:
    1.0 gal
  • Gross axle weight rating, front:
    450 lbs
  • Gross axle weight rating, rear:
    730 lbs
  • Transmission capacity:
    1 qt. (.95 l )
  • Primary chain case capacity:
    1.25 qt. (1.18 l )
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 114
  • Bore:
    4.0 in
  • Stroke:
    4.5 in
  • Displacement:
    113.99 in³
  • Compression ratio:
    10.5:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Air cleaner:
    Screamin' Eagle® round high-flow air cleaner with oiled-cotton filter element.
  • Exhaust:
    2-into-2 shorty dual; catalyst in muffler
  • Lubrication system:
    Pressurized, dry-sump with oil cooler
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    118.7 ft-lb
  • Engine torque (RPM):
    3,000
  • Horsepower:
    94 HP / 70 kW @ 4750 rpm
  • Lean angle, right (deg.):
    27.4
  • Lean angle, left (deg.):
    27.4
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    47 mpg (5 l/100 km)
  • Lean angle testing method:
    J1168
• Powertrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.311
  • Gear ratios (overall) 2nd:
    6.454
  • Gear ratios (overall) 3rd:
    4.793
  • Gear ratios (overall) 4th:
    3.882
  • Gear ratios (overall) 5th:
    3.307
  • Gear Ratios (overall) 6th:
    2.79
  • Final drive:
    Belt, 32/66 ratio
  • Clutch:
    Mechanical, 10 plate wet, assist & conventional
  • Transmission:
    6-Speed Cruise Drive®
• Chassis

  add remove
  • Front fork:
    Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; "beer can" covers
  • Rear shocks:
    Hidden, free piston, coil-over monoshock; 43mm stroke; cam-style preload adjustment
  • Wheels, front type:
    Chrome Steel Laced
  • Wheels, rear type:
    Chrome Steel Laced
  • Brakes, type:
    Solid, uniform expansion rotors
  • Brakes, caliper type:
    4-piston fixed front and 2-piston floating rear
  • Frame:
    Mild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; MIG welded; aluminum forged fender supports
  • Swingarm:
    Mild steel, tubular sections, stamped x-member, forged axle junctions; MIG welded; removable belt spacer
• Electric

  add remove
  • Lights (as per country regulation), Headlamp:
    All LED, low beam, high beam and signature position lamp
  • Lights (as per country regulation), Tail/Stop:
    Incandescent Zeppelin tail lamp
  • Lights, front signal lights:
    Incandescent bullets
  • Lights, rear turn signals:
    Incandescent bullet light bar
  • Gauges:
    5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication
  • Battery:
    Sealed, maintenance-free, absorbed glass mat (AGM) battery, 12V, 17.5Ah, 310 CCA at 0°F
  • Charging:
    Three-phase, 42 Amp system (390 Watts @13 Volts, 1000 rpm, 546 Watts max power @ 13 Volts, 2000 rpm)
  • Starting:
    1.6 kW electric with solenoid shift starter motor engagement
  • Auxiliary lamps:
    LED fog
  • Electric power outlet:
    USB A-type; output 5V at 2.4A
