Specifications

• Engine

  add remove
  • Engine:
    Standard
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    40
  • Torque (Ft Lbs):
    29.5
  • Valves:
    2
  • Valves Per Cylinder:
    2
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.31
  • Stroke (in):
    3.21
  • Displacement (cc):
    452
  • Compression ratio:
    11.5:1
• Transmission

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    88.4
  • Width (in):
    33.5
  • Height (in):
    51.8
  • Wheelbase (in):
    59.5
  • Ground Clearance (in):
    9
  • Wet Weight (lbs):
    432
  • Engine Displacement to Weight (cc):
    1.13
  • Fuel Capacity (gal):
    4.5
  • Dry Weight (lbs):
    399
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Front Suspension Size (in):
    1.7
  • Front Travel (in):
    7.9
  • Rear Travel (in):
    7.9
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Front Tire (Full Spec):
    90/90 R21
  • Rear Tire (Full Spec):
    140/80 R17
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    12.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.6
