Specifications

• Dimensions

  add remove
  • Length:
    102.4 in
  • Ground clearance:
    4.9 in
  • Rake (steering head):
    26
  • Trail:
    6.7 in
  • Wheelbase:
    1,625.0 in
  • Tires, front specifications:
    BW 130/60B19 61H
  • Tires, rear specifications:
    BW 180/55B18 80H
  • Fuel Capacity:
    6.0 gal
  • Oil capacity:
    5 qt.
  • Weight, as shipped:
    906 lbs
  • Weight, in running order:
    944 lb
  • Luggage capacity – volume:
    4.7 cu ft (0.132 m3)
• Engine

  add remove
  • Engine:
    Twin-Cooled™ Milwaukee-Eight® 117
  • Bore:
    4.1 in
  • Stroke:
    4.5 in
  • Displacement:
    117.35 in³
  • Compression ratio:
    10.2:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    Dual, with crossover
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    124.6 ft-lb
  • Lean angle, right (deg.):
    34.3
  • Lean angle, left (deg.):
    33.4
  • Fuel economy:
    0.00 mpg
• Powertrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.593
  • Gear ratios (overall) 2nd:
    6.65
  • Gear ratios (overall) 3rd:
    4.938
  • Gear ratios (overall) 4th:
    4
  • Gear ratios (overall) 5th:
    3.407
  • Gear Ratios (overall) 6th:
    2.875
• Chassis

  add remove
  • Wheels, optional style type:
    Denim Black and Contrast Gloss Black Tomahawk, Gloss Black and Contrast Smoked Satin Tomahawk
  • Wheels, front type:
    Gloss Black and Contrast Satin Tomahawk
  • Wheels, rear type:
    Gloss Black and Contrast Satin Tomahawk
  • Brakes, caliper type:
    32 mm, 4-piston fixed front and rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    Headlight, running lights, directional lights, neutral, low oil pressure, check engine, turn signals, security/fault indication,gear indication, neutral, low fuel warning, cruise control, ABS, Low Tire Pressure/TPMS indicator, Traction Control, Rain Mode,
  • Gauges:
    - Custom gauges styled to complement each CVO vehicle. Display features odometer, trip A, trip B, range to empty and gear indicator; and larger tell-tale indicators.
• Infotainment

  add remove
  • Infotainment system:
    Boom!™ Box GTS
  • Type:
    Full Color TFT
  • Watts per channel:
    75
  • Speakers:
    4
  • Speaker size:
    Boom! Audio Stage I
  • Headset specifications (if equipped):
    Boom! Audio 30K Wireless Headset
  • AM:
    Standard
  • FM:
    Standard
  • Weather Band (WB):
    Standard
  • SD Card, Flash Drive and MP3 — via USB Connection:
    Supported
  • Sirius^XM Presets:
    20 - P&A Upgrade (USA & Canada only)
  • Languages:
    English (US/UK)GermanSpanish (Mexico/Spain)French (Canada/France)ItalianPortuguese (Portugal/Brazil)RussianCzechPolishDutchTurkishJapanese
  • Hands-free mobile phone — via Bluetooth:
    Standard
  • Voice Recognition Languages: Phone functions only:
    English (US/UK)GermanSpanish (Mexico/Spain)French (Canada/France)ItalianPortuguese (Portugal/Brazil)RussianCzechPolishDutchTurkishJapanese
  • Voice Recognition Languages: Tuner / Media / Navigation:
    English (US/UK)GermanSpanish (Mexico/Spain)French (Canada/France)ItalianPortuguese (Portugal/Brazil)RussianCzechPolishDutchTurkishJapanese
  • Text-to-Speech (TTS) languages:
    English (US/UK)GermanSpanish (Mexico/Spain)French (Canada/France)ItalianPortuguese (Portugal/Brazil)RussianCzechPolishDutchTurkishJapanese
  • Rider / passenger intercom:
    Standard (Passenger Headset Sold Seperately)
  • Vehicle information screen:
    Standard
  • USB:
    USB/MTP/iPod/iPhone
  • Bluetooth:
    Phone/Media Supported
