Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
  • Capacity:
    800 cc
  • Bore:
    2.9 in
  • Stroke:
    2.4 in
  • Compression:
    11.3:1
  • Max Power:
    70 kW / 9500 rpm
  • Max Torque:
    58.3 ft-lb / 8050 rpm
  • System:
    Multipoint sequential electronic fuel injection
  • Exhaust:
    Stainless steel 3 into 1 header system, side mounted stainless steel muffler
  • Final Drive:
    O-ring chain
  • Clutch:
    Wet, multi-plate
  • Gearbox:
    6-speed
• Chassis

  add remove
  • Frame:
    Tubular steel trellis frame
  • Swingarm:
    Twin­sided, cast aluminum alloy
  • Front Wheel:
    Spoked 21 x 2.15 in
  • Rear Wheel:
    Spoked 17 x 4.25 in
  • Front Tyre:
    90/90-­21
  • Rear Tyre:
    150/70 R17
  • Front Suspension:
    WP 1.69 in (43 mm) upside down forks, with adjustable rebound and compression damping, 8.66 in (220 mm) travel
  • Rear Suspension:
    WP monoshock with remote oil reservoir, hydraulically adjustable preload, 8.46 in (215 mm) rear wheel travel
  • Front Brake:
    Twin 12 in (305 mm) floating discs, Brembo 2­piston sliding calipers, switchable ABS
  • Rear Brake:
    Single 10.04 in (255 mm) disc, Nissin single piston sliding caliper, switchable ABS
• Dimensions & Weights

  add remove
  • Width Handlebars:
    31.7 in
  • Height Without Mirror:
    54.7 in
  • Seat Height:
    840 - 860 mm
  • Wheelbase:
    60.8 in
  • Rake:
    23.4 º
  • Trail:
    3.7 in
  • Tank Capacity:
    5.0 gal
  • Dry Weight:
    459 lbs
